Powerful and high-capacity storage that fits in any environment
| CPU Model | CPU Quantity | CPU Core | CPU Architecture | CPU Frequency | Hardware Encryption Engine |
| Intel Xeon D-1531 | 1 | 6 | 64-bit | 2.2 (base) / 2.7 (turbo) GHz | Yes |
| System Memory | Memory Module Pre-installed | Total Memory Slots | Maximum Memory Capacity |
| 16 GB DDR4 ECC SODIMM | 16 GB (8 GB x 2) | 4 | 48 GB (8 GB x 2 + 16 GB x 2) |
| Drive Bays | Maximum Drive Bays with Expansion Unit | Compatible Drive Type* (See all supported drives) | Hot Swappable Drive* |
| 12 | 36 (DX1222 x 2) |
|
Yes |
| RJ-45 1GbE LAN Port | RJ-45 10GbE LAN Port | Out-of-Band Management LAN Port | USB 3.2 Gen 1 Port | Expansion Port | Expansion Port Type |
| 2 | 2 | 1 | 2 | 2 | Mini-SAS HD |
| PCIe Expansion |
| 1 x Gen3 x8 slot (x8 link) |
| Size (Height x Width x Depth) | Weight |
| 270 mm x 300 mm x 340 mm | 9.8 kg |
| System Fan | Fan Speed Mode | Easy Replacement System Fan | Power Recovery | Noise Level* | Scheduled Power On / Off | Wake on LAN / WAN | Power Supply Unit / Adapter | AC Input Power Voltage | Power Frequency | Power Consumption | British Thermal Unit |
| 120 mm x 120 mm x 2 pcs | Full-Speed Mode/ Cool Mode/ Quiet Mode | Yes | Yes | 25 dB(A) | Yes | Yes | 550 watts | 100V to 240V AC | 50/60 Hz, Single Phase |
|
|
| Operating Temperature | Storage Temperature | Relative Humidity | Operating Humidity |
| 0°C to 40°C (32°F to 104°F) | -20°C to 60°C (-5°F to 140°F) | 5% to 95% RH | 8% to 80% RH |
| FCC/ CE/ BSMI/ VCCI/ RCM/ UKCA/ EAC/ CCC/ KC/ BIS/ UL |
| 5 Years |
| RoHS Compliant |
|
|
Protect all your data with integrated security features and centralized access.
Share, back up, and access files, photos, surveillance video, and more.
15 watts under full operation keeps operating costs low
Store, sync, access, and share data from any device, wherever you are. Work together seamlessly across different platforms, accessing files through mobile apps, desktop clients, or a browser-based interface.
Work together with minimal slowdown using site-to-site file syncing, which can be configured to automatically synchronize individual files or folders.
Consolidate and automate backup tasks for workstations, file servers, VMs, SaaS applications, and more with Active Backup Suite. Administer device backups remotely through a centralized portal.
