i3
Series

HD4260-i3

4U 60-Bay High-density Server

FEATURES
4U High-density Storage Server supporting 60 hot-swap 3.5” SAS/SATA drive bays

Two external rear 2.5” SATA bays and two onboard M.2 (NGFF) M-Key 2280 slots
Supports dual Intel® Xeon® 3 Gen Scalable (Ice Lake) processors, delivering exceptional server performance and
rd
enhanced power efficiency
16 DDR4 DIMM slots for maximum memory performance
Expansion support: Up to 3 × PCIe Gen4 x16 slots, 2 × PCIe Gen4 x8 slots, 4 × Slimline x8 ports and 1 × OCP 3.0 slot
Onboard Baseboard Management Controller (BMC) for system management and IPMI control, with a dedicated BMC
management port
Front-to-back airflow and hot-swap redundant fans for optimal thermal efficiency
Trusted Platform Module (TPM) 2.0 onboard High-density
Supports 1600W (1+1) / 800W (2+2) redundant power supply, 80+ Platinum Server
efficiency
SPECIFICATIONS

Model Number InfiniPlus HD4260-i3
rd
Dual Intel® Xeon® 3 Gen Scalable Processors (Ice Lake)
Processor CPU TDP: 270W
Socket P+ (LGA-4189)
Chipset Intel® C621A Chipset
• 8 × Memory channels per CPU; 16 × DIMM slots support

Memory • DDR4 3200/2933MHz RDIMM/LRDIMM
• Supports up to 4TB LRDIMM/RDIMM
• System Power On/Off Button
• System Reset Button
Front Panel
• System ID Indicator
• 1 x USB 3.0 Type-A Ports
• Power Status

• Drive Activity
LEDs • System Alert
• LAN Activity
• System ID
Top-load 3.5”/2.5” hot swap 60 (SAS/SATA)
Drive Bays Rear panel 2.5" hot swap 8 NVMe / 2 × SATA (optional)
Internal M.2 2 x M.2 (NGFF) / M-Key / 2280
