i3
Series

R1210-i3

1U 10-Bay File Server

FEATURES
1U 10-Bay Server with 2.5” SAS/SATA/NVMe drives support

Two onboard M.2 (NGFF) M-Key 2280 slots
Supports dual Intel® Xeon® 3 Gen Scalable (Ice Lake) processors, delivering exceptional server performance and
rd
enhanced power efficiency
16 DDR4 DIMM slots for maximum memory performance
Expansion support: Up to 2 x PCIe Gen4 x16 slots, 1 x OCP v3.0 slot and 4 x Slimline x8 port
Onboard Baseboard Management Controller (BMC) for system management and IPMI control, with a dedicated BMC
management port
Front-to-back airflow with easy-swap redundant fans for optimal thermal conditions
Trusted Platform Module (TPM) 2.0 onboard
Onboard RAID support for levels 0, 1, 5, and 10 File Server
Supports 750W / 1100W (1+1) redundant power supply
SPECIFICATIONS

Model Number InfiniPlus R1210-i3
rd
Dual Intel® Xeon® 3 Gen Scalable Processors (Ice Lake)
Processor CPU TDP: 270W
Socket P+ (LGA-4189)
Chipset Intel® C621A Chipset
• 8 × Memory channels per CPU; 16 × DIMM slots

Memory • DDR4 3200/2933MHz RDIMM/LRDIMM
• Supports up to 4TB RDIMM/LRDIMM
• System Power On/Off Button
• System Reset Button
Front Panel
• System ID Indicator
• 2 × USB 3.0 Type-A Ports
• Power Status

• Drive Activity
LEDs • System Alert
• LAN Activity
• System ID
External 2.5” hot swap 8 (NVMe)
Drive Bays 2 (SATA)
2 × M.2 (NGFF) / M-Key / 2280
Internal (Onboard) M.2 2 × M.2 (NGFF) / M-Key / 2280
www.ebm.in
24
