i3
Series

• CPU0: 2 × PCIe Gen4 x16 slots + 1 × OCP v3.0
PCI 4.0 • CPU1: 1 × PCIe Gen4 x16 slot + 2 × PCIe Gen4 x8
Expansion Slots
• CPU0: 1 × Slimline x8 Gen4 port
Slimline x8 port
• CPU1: 3 × Slimline x8 Gen4 ports
• ASPEED AST2500 Advanced PCIe Graphics & Remote Management Processor
Graphics
• PCIe VGA/2D Controller
• Resolution: 1920 × 1200 @ 60Hz, 32bpp

• 1 × Slimline x8 connector
Internal I/O SATA
• 2 × SATA 3.0 (6 Gb/s) 7-pin connectors
Network • 1 × GbE RJ45 port for dedicated BMC management
Controllers • 1 × GbE RJ45 port for BMC shared NIC management
Rear I/O USB 2 × USB 3.0
Video Output 1 × external DB-15 VGA port
Serial Port 1 × external COM port jack
Security • Trusted Platform Module (TPM) 2.0 onboard
1600W (1+1) / 800W (2+2) Redundant PSU, 80+ Platinum
Power Supply
AC Input: 100~240V, 50/60Hz, 10–5A
System Cooling 4 × 80 × 38 mm hot swap fans
• Storage temperature: -10°C (14°F) to 60°C (140°F)
Environmental • Operating temperature: 0°C (32°F) to 35°C (95°F)
Specifications
• Storage operating humidity: 5% – 95% non-condensing
System • IPMI 2.0 compliant
Management • KVM over IP

• Virtual Media redirection

• Monitoring: temperature, fan, voltage, PSU sensors
• System temperature tracking
• System ID and fail indicator
• Remote power control (On / Off / Reset)
• SEL (System Event Log) message alerts via email
• SNMP (Simple Network Management Protocol) support
• Intel® Node Manager (Intel NM) support
Gross Weight (w/ PSU & Rail) Kg: 80
mm: 434 × 853 × 176
Dimensions (W x D x H)
inches: 17.1 × 33.6 × 6.9
Certification BIS, RoHS compliant
Warranty 3 Years + 2 Years Extended

Additional • HBA (FC, iSCSI & SAS) with RAID – OCP 3.0 / PCIe 4.0 ×8
Accessories • Dual-Port 1 GbE RJ45 Network Interface Card – PCIe 2.1 ×4

• Dual-Port 10 GbE RJ45 Network Interface Card – PCIe 3.0 ×8

• Dual-Port 10 GbE SFP+ Network Interface Card – OCP 3.0 / PCIe 4.0 ×8

• Quad-Port 10 GbE SFP+ Network Interface Card – OCP 3.0 / PCIe 4.0 ×16

• Dual-Port 25 GbE Network Interface Card – OCP 3.0 / PCIe 4.0 ×8

• Quad-Port 25 GbE Network Interface Card – OCP 3.0 / PCIe 4.0 ×16

• Dual-Port 100 GbE Ethernet Network Adapter – OCP 3.0 / PCIe 4.0 ×16

• Dual-Port 200 GbE Ethernet Network Adapter

• Dual-Port 40 GbE QSFP+ Ethernet Adapter with direct attach cabling support (up to 10 m)
• Quad-Port 16 GbE Fibre Channel Adapter – OCP 3.0 / PCIe 4.0 ×8

• Dual-Port 32 GbE Fibre Channel Adapter – OCP 3.0 / PCIe 4.0 ×8
Mounting Standard 28” tool-less slide rail
