Page 16 - EBM- E-Catalogue.cdr

G5Series

R3216-G5

3U 16-Bay File Server View More
3U 16-Bay Storage Server with SAS/SATA hot-swap drives support
Two external rear 2.5” SATA, two onboard M.2 2280 Gen4 x4 and PFR with M.2 connector (optional)

th
Powered by the latest dual Intel® Xeon® 5 Gen Emerald Rapids / 4 Gen Sapphire Rapids processors for
th
exceptional computing performance and power efficiency
Supports 16 DDR5 RDIMM slots for maximum memory performance
Supports 5 x16 PCIe 5.0/CXL + 1 x8 PCIe 5.0/CXL
Supports three MCIO x8 PCIe 5.0/CXL lanes, total 24 PCIe 5.0 lanes
Onboard Baseboard Management Controller for advanced system management and IPMI control
Trusted Platform Module (TPM) 2.0 onboard
TCM 2.0 interface for extension
Supports 800W / 1200W (1+1) redundant power supply

SR4224-G5

4U 24-Bay Storage Server View More
4U 24-Bay Storage Server with SAS/SATA drives support
Two external rear 2.5” SATA, two onboard M.2 2280 Gen4 x4 and PFR with M.2 connector (optional)

Powered by the latest dual Intel® Xeon® 5 Gen Emerald Rapids / 4 Gen Sapphire Rapids processors for
th
th
exceptional computing performance and power efficiency
Supports 16 DDR5 RDIMM Slots for maximum memory performance
Supports 5 x16 PCIe 5.0/CXL + 1 x8 PCIe 5.0/CXL
Supports three MCIO x8 PCIe 5.0/CXL lanes, total 24 PCIe 5.0 lanes
Onboard Baseboard Management Controller for advanced system management and IPMI control
Trusted Platform Module (TPM) 2.0 onboard
TCM 2.0 interface for extension
Supports 1200W (1+1) redundant power supply

12

www.ebm.in
