G5
Series

R1204-G5

1U 4-Bay File Server

FEATURES
1U chassis with 4 × 3.5"/2.5" hot-swap SATA/SAS/NVMe bays
Two internal 2.5” SATA and Two onboard M.2 2280 Gen4 x4 and PFR with M.2 connector (optional)
th
th
Powered by the latest dual Intel® Xeon® 5 Gen Emerald Rapids / 4 Gen Sapphire Rapids processors for exceptional
computing performance and power efficiency
Supports 16 DDR5 RDIMM slots for maximum memory performance
Supports 1 x16 PCIe 5.0
Supports three MCIO x8, total 24 PCIe 5.0/CXL lanes
Onboard Baseboard Management Controller for advanced system management
and IPMI control
Trusted Platform Module (TPM) 2.0 onboard
TCM 2.0 interface for extension File Server
Supports 750W / 1100W (1+1) CRPS redundant power supply, 80+ Platinum
efficiency
SPECIFICATIONS

Model Number InfiniPlus R1204-G5
th
th
Dual Intel® Xeon® 5 Gen Emerald Rapids & 4 Gen Sapphire Rapids
Processor CPU TDP: 350W Max
Socket 2 × LGA4677-X (Socket E1)
Chipset Intel® C741 Chipset
• 8 x Memory channels per CPU; 16 DDR5 RDIMM slots support

Memory • Max DDR5 5600/4800MHz RDIMM (1DPC)
• Support up to 4TB (3DS RDIMM)
• System Power On/Off Button
• System Reset Button
Front Panel
• System ID Indicator
• 2 x USB 3.0 Type-A Ports
• P ower Status

• Drive Activity
LEDs • S ystem Alert
• LAN Activity
• S ystem ID

External 3.5”/2.5” hot swap 4 (SAS/SATA/NVMe)
Drive Bays 2.5” OS 2 (SATA)
Internal
M.2 2 x M.2 (NGFF) / M-Key / 2280
