Page 9 - EBM Final Catalogue.cdr

G5
Series
Series

• 2 x PCIe x16 slots (FHHL) (Reserve GPU card support retention mechanical bracket)
Expansion Slots PCIe5.0 • 2 x OCP 3.0 bays (PCIe x16 width)
MCIO 12 x MCIO x8 PCIe 5.0
Riser Card 2 x PCIe 5.0 x16 cable CEM
Aspeed AST2500 Advanced PCIe Graphics & Remote Management Processor
Graphics • PCIe VGA/2D Controller
• Resolution: 1920 x 1200 @ 60Hz, 32bpp
LAN 1 x GbE port for dedicated BMC management
USB 2 x USB 3.2 Gen1 Type-A ports
Rear Ports 1 x external DB-15 VGA port
Video Output
1 x Mini Display port
Serial Port 1 x external RJ45 COM port
Power Supply 1600W Redundant Power Supply, 80+ Platinum/Titanium
System Cooling 6 x 60 x 56 mm easy-swap fans with ABS material plastic air-duct

• Storage temperature: -10°C (14°F) ~ 60°C (140°F)
Environmental • Operating temperature: 0°C (32°F) ~ 35°C (95°F)
Specifications
• Storage operating humidity: 5% ~ 95% non-condensing
System • IPMI 2.0 compliant
Management • KVM over IP
• Virtual Media redirection

• Monitoring of temperature, fan, voltage, and PSU sensors
• System temperature tracking
• System ID and fail indicator
• Remote power control (On / Off / Reset)
• SEL (System Event Log) message alerts via email
• SNMP (Simple Network Management Protocol) support
• Intel® Node Manager (Intel NM) support
Gross Weight (w/ PSU & Rail) Kg: 29
mm: 438 x 800 x 87.5
Dimensions (W x D x H)
inches: 17.2 x 31.5 x 3.5
Certification BIS, RoHS compliance
Warranty 3 Years + 2 Years Extended

Additional • HBA (FC, iSCSI & SAS) with RAID – OCP 3.0 / PCIe 4.0 ×8

Accessories • Dual-Port 1 GbE RJ-45 Network Interface Card – PCIe 2.1 ×4

• Dual-Port 10 GbE RJ-45 Network Interface Card – PCIe 3.0 ×8
• Dual-Port 10 GbE SFP+ Network Interface Card – OCP 3.0 / PCIe 4.0 ×8

• Quad-Port 10 GbE SFP+ Ethernet Network Adapter – OCP 3.0 / PCIe 4.0 ×16

• Dual-Port 25 GbE Network Interface Card – OCP 3.0 / PCIe 4.0 ×8

• Quad-Port 25 GbE Network Interface Card – OCP 3.0 / PCIe 4.0 ×16

• Dual-Port 100 GbE Ethernet Network Adapter – OCP 3.0 / PCIe 4.0 ×16

• Dual-Port 200 GbE Ethernet Network Adapter

• Dual-Port 40 GbE QSFP+ Ethernet Adapter (Direct-Attach Cable support up to 10 m)

• Quad-Port 16 GbE Fibre Channel Adapter – OCP 3.0 / PCIe 4.0 ×8

• Dual-Port 32 GbE Fibre Channel Adapter – PCIe 4.0 ×8
Mounting Standard 28" tool-less slide rail
