G5
             Series
             Series








                                            •  2   x PCIe x16 slots (FHHL)
                               PCIe 5.0
               Expansion Slots              •  2   x OCP 3.0 bays (PCIe x16 width)
                               MCIO         12 x MCIO x8 PCIe 5.0
               Riser Card      2 x PCIe 5.0 x16 cable CEM
                               Aspeed AST2500 Advanced PCIe Graphics & Remote Management Processor
               Graphics        •  PCIe VGA/2D Controller
                               •  Resolution: 1920 x 1200 @ 60Hz, 32bpp
                               LAN          1 x GbE port for dedicated BMC management
                               USB          2 x USB 3.2 Gen1 Type-A ports
               Rear Ports                   1 x external DB-15 VGA port
                               Video Output
                                            1 x Mini Display port
                               Serial Port   1 x external RJ45 COM port
               Power Supply    1600W Redundant Power Supply, 80+ Platinum/Titanium
               System Cooling  8 x 40 x 56 mm easy-swap fans with ABS material plastic air-duct
                               •  Storage temperature: -10°C (14°F) ~ 60°C (140°F)
               Environmental   •  Operating temperature: 0°C (32°F) ~ 35°C (95°F)
               Specifications
                               •  Storage operating humidity: 5% ~ 95% non-condensing
               System          •  IPMI 2.0 compliant
               Management       •  KVM over IP
                               •  Virtual Media redirection

                               •  Monitoring of temperature, fan, voltage, and PSU sensors

                               •  System temperature tracking
                               •  System ID and fail indicator
                               •  Remote power control (On / Off / Reset)
                               •  SEL (System Event Log) message alerts via email
                               •  SNMP (Simple Network Management Protocol) support
                               •  Intel® Node Manager (Intel NM) support
               Gross Weight    (w/ PSU & Rail)  Kg: 20
                                             mm: 438 x 800 x 43.75
               Dimensions      (W x D x H)
                                             inches: 17.2 x 31.5 x 1.75
               Certification    BIS, RoHS compliance
               Warranty        3 Years + 2 Years Extended
               Additional      •  HBA (FC, iSCSI & SAS) with RAID – OCP 3.0 / PCIe 4.0 ×8


               Accessories     •  Dual-Port 1 GbE RJ-45 Network Interface Card – PCIe 2.1 ×4




                               •  Dual-Port 10 GbE RJ-45 Network Interface Card – PCIe 3.0 ×8


                               •  Dual-Port 10 GbE SFP+ Network Interface Card – OCP 3.0 / PCIe 4.0 ×8


                               •  Quad-Port 10 GbE SFP+ Ethernet Network Adapter – OCP 3.0 / PCIe 4.0 ×16


                               •  Dual-Port 25 GbE Network Interface Card – OCP 3.0 / PCIe 4.0 ×8


                               •  Quad-Port 25 GbE Network Interface Card – OCP 3.0 / PCIe 4.0 ×16
                               •  Dual-Port 100 GbE Ethernet Network Adapter – OCP 3.0 / PCIe 4.0 ×16


                               •  Dual-Port 200 GbE Ethernet Network Adapter


                               •  Dual-Port 40 GbE QSFP+ Ethernet Adapter (Direct-Attach Cable support up to 10 m)




                               •  Quad-Port 16 GbE Fibre Channel Adapter – OCP 3.0 / PCIe 4.0 ×8
                               •  Dual-Port 32 GbE Fibre Channel Adapter – PCIe 4.0 ×8
               Mounting        Standard 28" tool-less slide rail
