AF2224-G5

2U 24-Bay All-Flash Server

FEATURES Ultra High Throughput upto 100/75 GBPS (Read/Write)

2U Ultra high-performance All-Flash Server with 24 x 2.5” front NVMe hot-swappable bays
2 x 2.5” rear SATA hot-swappable bays and 2 x M.2 connector onboard
Powered by the latest dual Intel® Xeon® 5 Gen Emerald Rapids / 4 Gen Sapphire Rapids processors for exceptional
th
th
computing performance and power efficiency
Supports 32 x DDR5 RDIMM memory slots - 16 slots per CPU

Flexible I/O Options: 2 x OCP 3.0 bays, 2 x PCIe x16 slots (FHHL) (PCIe x16 Gen5), 12 x MCIO x8 interfaces, supporting
a total of 24 x PCIe Gen5 NVMe drives
Onboard Baseboard Management Controller for advanced system management
and IPMI control
Trusted Platform Module (TPM) 2.0 onboard All-Flash
Server
Supports 1600W (1+1) redundant power supply
SPECIFICATIONS

Model Number InfiniPlus AF2224-G5
th
th
Dual Intel® Xeon® 5 Gen Emerald Rapids & 4 Gen Sapphire Rapids
Processor CPU TDP: 350W Max
Socket 2 × LGA4677-X (Socket E1)
Chipset Support Intel® Emmitsburg PCH (C741 Chipset)

• DDR5 4800MHz (1DPC)
System Memory • DDR5 5600MHz (1DPC) 4400MTS (2DPC) by Emerald Rapids CPU
• Total 32 memory slots; 16 slots per CPU (2DPC)
• System Power On/Off Button
• System Reset Button
Front Panel • System Alert Indicator
• System ID Indicator
• 2 x USB 3.0 Type-A Ports
• Power Status Indicator
• Drive Activity Indicator
LEDs • LAN Activity Indicator
• Warning Indicator
• System ID Indicator

24 x PCIe Gen5 NVMe
External 2.5" hot swap
Drive Bays 2 x SATA Rear
Internal (Onboard) M.2 2 x M.2/M-Key/22110/2280 (PCIe Gen4)
