G5Series

HD4260-G5

4U 60-Bay High-density Server View More

4U High-density Storage Server supports 60 hot-swap 3.5” SAS/SATA drive bays
Two external rear 2.5” SATA, two onboard M.2 2280 Gen4 x4 and PFR with M.2 connector (optional)

th
th
Powered by the latest dual Intel® Xeon® 5 Gen Emerald Rapids / 4 Gen Sapphire Rapids processors for
exceptional computing performance and power efficiency
Supports 16 DDR5 RDIMM slots for maximum memory performance
Supports 5 x16 PCIe 5.0/CXL + 1 x8 PCIe 5.0/CXL
Supports three MCIO x8 PCIe 5.0/CXL lanes, total 24 PCIe 5.0 lanes
Onboard Baseboard Management Controller for advanced system
management and IPMI control
Trusted Platform Module (TPM) 2.0 onboard
TCM 2.0 interface for extension
Supports 800W (2+2) / 1600W (1+1) redundant power supply

R1204-G5

1U 4-Bay File Server View More
1U chassis with 4 × 3.5"/2.5" hot-swap SATA/SAS/NVMe bays
Two internal 2.5” SATA and Two onboard M.2 2280 Gen4 x4 and PFR with M.2 connector (optional)
th
th
Powered by the latest dual Intel® Xeon® 5 Gen Emerald Rapids / 4 Gen Sapphire Rapids processors for
exceptional computing performance and power efficiency
Supports 16 DDR5 RDIMM slots for maximum memory performance
Supports 1 x16 PCIe 5.0
Supports three MCIO x8, total 24 PCIe 5.0/CXL lanes
Onboard Baseboard Management Controller for advanced system management and IPMI control
Trusted Platform Module (TPM) 2.0 onboard
TCM 2.0 interface for extension
Supports 750W / 1100W (1+1) CRPS redundant
power supply, 80+ Platinum efficiency
